Description
Frame and fork
– Frame: Clean X1 20” 1 1/8” – 1.5” tapered, post mount disc brake mounts.
– Forks: Clean X2 20”, with 1 1/8” – 1.5” tapered, post mount disc brake mounts.
Wheels
– Front: S1 Clean hubs, 20” S1 double wall rim. Tire – Clean Koala 20* 2.0.
– Rear: S1 Clean hubs, 19” S1 double wall rim.. Tire – Clean Koala 19” * 2.5.
Brakes
– Front brake: Magura MT Sport hydraulical disc brakes, 160mm rotor.
– Rear brake: Magura MT Sport hydraulical disc brakes, 160mm rotor.
Drivetrain
– Cranks: Clean ISIS 160mm, black.
– Freewheel: Clean X2 108.9, 18t, 108 engagement points, 9 pawls.
– Chain: KMC Z1 eHX narrow, silver.
– Rear sprocket: Clean 12T, screw on.
– Pedals: Clean Single cage.
– Tensioner: Clean.
Steering
– Headset: Tapered 1 1/8” – 1.5”.
– Stem: Clean 150mm x 35º, for 31.8mm handlebars.
– Handlebar: Clean aluminium 103mm, 720mm width
Geometry
– Wheelbase: 1005mm
– Chainstay length: 350mm
– Bottom bracket rise: +87mm
– Head angle: 72º
