Description
Frame kit
– frame: Jitsie Varial Race 970mm disc tapered.
– fork: Jitsie Varial Race 370mm disc tapered 1.1/8″ – 1.4″ with 10mm thru axle.
Features frame
– manufactured from aerospace 6061-T6 aluminium.
– minimalistic design with a focus on performance and durability.
– 110mm high CNC machined head tube designed for semi-integrated tapered headset.
– CNC machined 68mm wide bottom bracket yoke for ISIS bottom bracket.
– CNC machined post mount rear disc brake support for 162mm rear brake disc Race includes integrated rear dropout for increased strength.
– CNC machined horizontal dropouts distanced 116mm apart come supplied with steel snail cam bolts.
– sandblasted silver finish with Jitsie Race graphics.
– frame comes supplied with lightweight silicon seat plug.
– frame allows for the Jitsie aftermarket seat to be installed.
Geometry
– wheelbase: 970mm.
– chainstay length: 350mm.
– bottom bracket height: 80mm.
– head tube: 110mm.
– head tube angle: 71.5°.
(geometry based on Jitsie Varial Race fork 370mm and +-45mm offset)
Wheels
– hub front / rear: Jitsie 100mm 28h disc Race black / Jitsie 116mm 32h disc Race black.
– rim front / rear: Jitsie 20″ 32mm 28h black / Jitsie 19″ 48mm 32h black.
– spokes / nipples: inox 1.8mm silver / aluminium silver.
– tyre front / rear: Jitsie Reverz 20″x2.0 / Jitsie Reverz 19″x2.6.
– tubes: Jitsie 20″ light 0.9mm.
Components
– headset: Jitsie semi-integrated tapered 1.1/8″ – 1.4″.
– headset spacer: Jitsie 5mm carbon.
– stem: Jitsie sloped 130mm 25° Race stem with clamp set and stem cap Race black.
– handlebar: Jitsie 31.8mm 730x90mm carbon with Jitsie handlebar pad.
– grips: foam.
– front brake: Jitsie disc brake master cylinder Race / Jitsie brake hose / Jitsie disc brake caliper Race with Jitsie brake pads Race / Jitsie brake disc 160mm Race.
– rear brake: Jitsie disc brake master cylinder Race / Jitsie brake hose / Jitsie disc brake caliper Race with Jitsie brake pads Race / Jitsie brake disc 162mm Race / Jitsie brake disc protector black.
Drivetrain
– bottom bracket: Jitsie ISIS titanium 123mm Race.
– cranks: Jitsie 160mm black.
– pedals: Jitsie simple cage black.
– freewheel: Jitsie 135.9 17t Race.
– protector: Jitsie bash plate black.
– sprocket: Jitsie steel 13t.
– chain: KMC K1SL gold.
– chain tensioner: Jitsie aluminium/steel snail cams.
Weight – 7.85kg including pedals and handlebar pad
Extra
– bike comes with a sheet with fork stickers and a selection of Jitsie stickers.
– We reserve the right to partially modify the components of the bike according to available stocks and in harmony with the original specifications. The pictures shown are non-contractual.
