Description
Frame and Forks
– Frame: CZAR 20″，disc brake mounts, 135 mm spacing rear hub.
– Fork: ECHO integrated disc.
Wheels
– Front hub: Echo TR, black.
– Rear hub: Echo TR 135 mm splined black.
– Front rim: CZAR 20″ no holes, black.
– Rear rim: CZAR 20″ no holes, black.
– Tyres: Maxxis 20″ Creepy Crawler x 2.0.
Brakes
– Front brake: Avid FR5 lever and BB5 mechanical disc brake, 160 mm.
– Rear brake: Avid FR5 lever and BB5 mechanical disc brake, 160 mm.
Optional brakes – see Brakes category.
Drivetrain
– Cranks: ECHO TR ISIS splined, 160 mm.
– Freewheel: ECHO TR 108 points 18t, splined.
– Rear sprocket: ECHO 12t, splined.
– Pedals: ECHO TR platform.
– Bottom bracket: ECHO spanish style ISIS, integrated.
– Bashring: ECHO 7075 – T6 full cover, 18t.
Steering
– Headset: ECHO TR.
– Stem: CZAR forged 6061 – T6 90mm x 40°.
– Handlebar: CZAR Street 7075 – T6 aluminium riser.
