Frame kit:
– Frame: Jitsie Varial 740mm V-brake.
– Fork: Jitsie Varial 300mm with V-brake mounts.
Features frame:
– Manufactured from aerospace 6061-T6 aluminium.
– Minimalistic design with focus on performance and durability.
– 110mm high CNC machined head tube designed for semi-integrated headset.
– 68mm wide bottom bracket shell for ISIS bottom bracket.
– V-brake mounts which also accept aftermarket Magura Evo2 rim brake clamps.
– CNC machined horizontal dropouts distanced 116mm apart come supplied with steel snail cam bolts.
– Sandblasted and black anodized finish with Jitsie graphics.
– Frame comes supplied with lightweight silicon seat plug.
– Frame allows for the Jitsie aftermarket seat to be installed.
Wheels:
– Hub front / rear: HS100 28h / HS116 32h.
– Rim front / rear: 18″ 32mm 28h / 18″ 32mm 32h.
– Spokes / nipples: inox 1.8mm / aluminium.
– Tyre front / rear: Ziggy 18″x2.25 / Ziggy 18″x2.25.
– Tubes: 18″ light 0.9mm.
Components:
– Headset: semi-integrated 1 1/8″.
– Headset spacer: 5mm aluminium.
– Stem: 90mm 35°.
– Handlebar: 31.8mm 580x75mm.
– Grips: foam.
– Front brake: V-brake.
– Rear brake: V-brake.
Drivetrain:
– Bottom bracket: square taper 124.5mm.
– Cranks: 140mm.
– Freewheel: 108.9 16t.
– Protector: bash ring.
– Sprocket: steel 12t.
– Chain: KMC Z610HX.
– Chain tensioner: snail cams.
Geometry:
– Wheelbase: 740mm
– Chainstays: 280mm
– Bottom bracket height: 25mm
– Headtube: 110mm
– headtube angle: 71.5°
(geometry based on Jitsie Varial fork 300mm and +45mm offset)
